Outdoor Solar Powered Smart Cabinet With MPPT Controller Rated Discharge Current 20A

Large Image : Outdoor Solar Powered Smart Cabinet With MPPT Controller Rated Discharge Current 20A

Product Details:

Place of Origin:	Shen Zhen, China (Mainland)
Brand Name:	ESTEL
Certification:	ISO9001, CE, 3C, FCC, TLC, IP55
Model Number:	ETDBQU2082SPG

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	negotiation
Packaging Details:	wooden case
Delivery Time:	15-20 working days
Payment Terms:	T/T
Supply Ability:	10,000 sets per month

Contact Now

Detailed Product Description

Material:	Galvanized Steel, Single Wall	External Size:	WDH380x220x500mm(different Size Are Optional)
Cable Entry:	At Cabinet Bottom	Installation Method:	Pole Mount
Ip Rating:	IP55	Working Temperature:	-20°C ~ 70°C
Color:	Customized	Grounding Protection:	Copper Bar
Application:	Telecommunication, Base Station, Electronic Ect, Outdoor Electronic Equipment, FTTX Network/Telecom	Type:	Telecom Outdoor Cabinet
Service:	OEM ODM	Door::	With One Front Door

Outdoor Solar Powered Smart Box With MPPT Controller Rated Discharge Current 20A

1, Outdoor Solar Powered Cabinet Specs:

Parameter	Specifications
Solar input	Solar battery input, <100VDC (must greater than storage battery voltage)
Battery	DC12V (customer provide)
DC output	DC output 3 channel, can detect voltage and current
RS232	Standard RS232 interface
RS485	Standard RS485 interface
Alarm input	3 channels, dry-connector input
Alarm input	channel 1 is default for the door open/closed detected;
10/100/1000 network port	1*10/100/1000Base-TX
Reset key	>5s press recovery to factory default
MPPT controller	Battery voltage: 12V/24V/Auto
	Solar input voltage: <100V
	MPPT efficiency: >99%
	Rated discharge current: 20A
Working temperature	-20℃~70℃
LCD screen	Size:108mm(L)64.8mm(W), Resolution ratio:800480, with touch-control
Storage temperature	-40℃~85℃
Humidity	0~95%(No condensation)
Dimension(H×W×D)	500mm×380mm×220mm
Material	Metal
Colour	White
Net-weight	15KG
Consumption	Self consumption<15W
Downlink ports	1~8 ports: 10/100/1000Base-TX 30W PoE
Downlink ports	RJ45(IEEE802.3af/at)
Uplink ports	9~10 ports: 1000M SFP slots
Working mode	Default: common switch.
Working mode	VLAN: 1~8 ports are isolated, only can communicate with the uplink ports; restrain the network storm; close flow control.
Switch fabric	5.6Gbps
Though put	4.2Mpps
Buffer	12KB
MAC address table	4K
Protection	Surge: 6KV, standard: IEC61000-4-5
Protection	ESD: 6KV: contact / 8KV: air, standard:IEC61000-4-2

2, Outdoor Cabinet With MPPT Controller Drawing:

3, Outdoor Cabinet Pictures:

Outdoor Solar Powered Smart Cabinet With MPPT Controller Rated Discharge Current 20A

4, Outdoor Cabinet Packaging Info:

Part number	Describe
Part number	Describe
ETDBQU2082SPG	Outdoor smart solar powered cabinet
	Solar <100V input;
	810/100/1000M PoE ports +21000M SFP ports switch;
	MPPT controller;
	control unit;
	Provide DC 3 channel power output;
	Storage battery type: DC12V, Pb acid or Lithium type(customer provide);
	Circuit-breaker and surge protector;
	Metal box housing 500380220mm;
