Anti Corrosion Powder Coated Thermostatic IP65 Outdoor Telecom Cabinet With Front Rear Access

Large Image : Anti Corrosion Powder Coated Thermostatic IP65 Outdoor Telecom Cabinet With Front Rear Access

Product Details:

Place of Origin:	Shenzhen, China (Mainland)
Brand Name:	ESTEL
Certification:	ISO9001, CE, 3C, FCC, TLC, IP55
Model Number:	132090820050001

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Wooden case
Delivery Time:	15-20 working days
Payment Terms:	T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability:	8,000 sets per month

Contact Now

Detailed Product Description

Monitoring Unit:	1U, DC48V	Cabinet Lock:	Anti-theft Three Point Lock(support Padlock)
Certificates:	CE	External Size:	WDH 8008001800mm
Material:	Galvanized Double Wall With Insulation	Color:	Grey/ Optional
Cooling System:	Air Conditioner	Ip Rating:	IP65

Anti Corrosion Powder Coated Thermostatic IP55 Outdoor Telecom Cabinet With Front Rear Access

1. Cabinet Application

The Anti Corrosion Powder Coated Outdoor Telecom Cabinet is mainly used in wireless communication base station, such as 4G system, communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.

2.Cabinet Product Details

Items	Technical Parameter
Dimension	External Dimension: W×D×H 900×800×2000mm
Layout	1 compartment
Equipment Installation Method	19” rack
Doors	With one front door and one back door, and anti-theft three point lock for outdoor cabinet (support padlock).
Material	Galvanized Steel, double wall with insulation
Ingress Protection	IP65
Temperature Control	Air conditioners and fans
Lighting	48V LED lamps
Temperature	Working Temperature: -40°C ~ +55°C
	Storage Temperature: -50°C ~ + 70°C
	Transport Temperature: -50°C ~ +70°C
Solar Radiation Intensity	1120 ×(1±5%)W/m2
Environment Monitoring Unit	1U, DC48V
Alarm sensors	Water sensor Smoke sensor Temperature and Humidity sensor Shock sensor Door sensor
Power Distribution Unit	Grade B Lightning Proof
Package	Wooden Case with pallets

3. Cabinet Appearance and Surface Treatment

Cabinet surface coating is outdoor special powder coating, with white gray color (PANTONE 428C). The coating complies with GB/T 3181-2008 requirement.

4.Cabinert Hinges

Anti Corrosion Powder Coated Thermostatic IP65 Outdoor Telecom Cabinet With Front Rear Access

5. Cabinet Key features

(1) The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment.

(2) Cabinet cooling system: air conditioners and fans

(3) The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding. There are cable inlet individually for power cable, signal cable and optical cable.

(4) All the cables used in the cabinet are made from flame retardant materials.

(5)Protection grade :IP55.

(6) Security design: Embedded doors, embedded hinges, 3-point security locks.

6.Cabinet Package

Anti Corrosion Powder Coated Thermostatic IP65 Outdoor Telecom Cabinet With Front Rear Access
