IP65 Three Bay Air Conditioner Cooling Outdoor Telecom Cabinets With CE Certificates

IP65 Three Bay Air Conditioner Cooling Outdoor Telecom Cabinets With CE Certificates

1.Cabinet Features

• External dimentions is W*D*H 2400*900*1800mm

• Gray color

• Sandwitch structure with heat insulation

• Top cover shades cabinet from the sun

• Three anti-theft front doors

• Anti-theft three point lock

• Individual cable entry holes from bottom of the cabinet

• Cooling system uses aire conditioner and fan.

• The door sensor, water sensor, smoke sensor, temperature and humidity sensor optional

• Flame retardant comply with GB5169.7 test A

• IP55 protection level

• CE certificates

• Floor mounting type

• Package:Wooden case with pallets

2.Cabinet Overview

This series there bay cabinet is a perfect choice for outdoor racking requirements.It offers a secure,climate controlled environment for any electronic equipment. Being made of galnarized steel,it’s strong enough to rack even the heaviest equipment.For those who need more than just standard enclosure, this series can also offer a truly the security of customized solution with lots of available options, providing a climate-controlled environment for any electronic equipment, electrical load panels and cable entry solutions.

3. Cabinet Application Types

Suitable used for outdoor application,such as: Telecommunications,Base station,Trailer-based communications,Fiber Optics and Military and etc.

4. Cable Connections

Use anti-loose threaded connection as structure and bearer connection.Anchor bolt for fixing cabinet use hot dip galvanized bolts.

Door hings use inner hinge mode.

5. Air Conditioner Installation

Air conditioner is installed on the front wall.

6. Cabinet Pictures
