DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet

China DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet supplier
DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet supplier DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet supplier

Large Image :  DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet

Product Details:

Place of Origin: China
Brand Name: ESTEL
Certification: ISO9001, CE, 3C, FCC, TLC, IP55
Model Number: ET6060100-BA

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: wooden case
Delivery Time: 10-15 working days
Payment Terms: L/C,D/A,T/T, Western Union, Paypal, etc
Supply Ability: 5,000 sets per month
Contact Now
Detailed Product Description



DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet



Quick Details:



Place of Origin: Shenzhen, China (Mainland)

External Size: H×W×D 1000×600×600mm

Internal Size H×W×D 700×520×520mm

Brand Name: ESTEL Structure: double wall, with insulation, sandwich structure
Model Number: ET6060100-BA Cabinet Layout: one compartment, for installing batteries
Product Name: Outdoor Battery Cabinet Cabinet Lock: anti-theft three point lock
Certification: ISO9001, CE, 3C, FCC, TLC, IP55 Protection Level: IP55
Application: Outdoor telecom base station Cable Inlet: at cabinet bottom
Material: galvanized steel Illumination: DC48V LED lamp
Heat Insulation: PEF Structure: assembled
Color: grey (support custom made) Cooling: DC48V air conditioner and DC48V fans
Coating: anti-corrosion outdoor powder coating Cooling Options: heat exchanger, peltier air conditioner, AC220V air conditioner



Payment & Shipping Terms:



Minimum Order Quantity: 1 set
Price: negotiation
Payment Terms: L/C,D/A,T/T, Western Union, Paypal, etc
Supply Ability: 5,000 sets per month
Delivery Time: 10-15 working days
Packaging Details: wooden case



1. Specifications

(1) Technical Parameters



Item Type Technical Parameter
Structure Dimension

External Size: H×W× 1000×600×600mm

Internal Size H×W×D 700×520×520mm

Layout One compartment
Installation Method Battery shelves
Door With one front door; with anti-theft three point lock for outdoor cabinet (support padlock)
Material Galvanized steel; sandwich structure, double walls, with heat insulation between two walls. Outer plate thickness: 0.5mm, inner plate thickness: 0.5mm, insulation: 45mm.
Structure Assembled
Ingress Protection IP55
Temperature Control Cooling DC48V air conditioner and DC48V fans
Lighting LED lamp 48V LED lamp
Temperature Temperature Working Temperature: -40°C ~ +55°C
Storage Temperature: -50°C ~ + 70°C
Transport Temperature: -50°C ~ +70°C
Humidity Relative Humidity 5% ~ 100%
Pressure Air Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity Solar Radiation Intensity 1120 × (1±5%)W/m2



(2) Accessories List



No. Item Quantity Unit Specs
1 Outdoor Battery Cabinet 1 Set

(1)External Size: H×W× 1000×600×600mm

Internal Size H×W×D 700×520×520mm

(2) One compartment;

(3) With one front door; with anti-theft three point lock for outdoor cabinet (support padlock)

(4) Galvanized steel; sandwich structure, double walls, with heat insulation between two walls. Outer plate thickness: 0.5mm, inner plate thickness: 0.5mm, insulation: 45mm.

2 Air Conditioner 1 Set

Cooling capacity: 400W;

Power supply: DC48V.

3 Fans 2 PC 12025, DC48V
4 LED Lamp 1 PC DC48V
5 LED sensor 1 PC Control LED on/off. When cabinet door is open, the LED lamp will automatically turn on; when cabinet door is closed, the LED lamp will automatically turn off.
6 Package 1 Set Wooden Case



Cabinet Diagram:





DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet

DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet





2. Description

2.1 Cabinet Material



The cabinet is made of galvanized steel, with double walls, thickness of outer plate: 0.5mm, thickness of inner plate: 0.5mm. There are heat insulation between inner wall and outer wall. The insulation material is 45mm PEF, heat insulation coefficient: 0.035W/m·K. The cabinet is assembled type.



2.2 Cabinet Structure



The cabinet includes battery shelves. The cabinet includes one air conditioner and fans, installed on front door.



2.3 Cabinet Door and Lock



The cabinet includes one front door. The cabinet door uses embedded structure. The door opening angle is larger than 110°and the door limit device can limit the opening angle. The lock is theftproof three point lock, supporting padlock.



2.3.1 Door lock theft proof design



  • Damage resistance of the theft proof lock meets GA/T 73-1994 “Mechanical Anti-theft Lock” class B requirement, supporting padlock.



DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet



Three point lock



DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet

DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet



2.4 Cable Inlet



Feeder cable and other external cables all use bottom wiring method.



DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet

2.5 Grounding Protection



  • The cabinet includes grounding copper bar with anti-corrosion coating. There are enough screws for wiring connection terminals.
  • The metal part of the cabinet should be interconnected and be connected with grounding bar. Connection resistance between any two points is lower than 0.1Ω.
  • Protective earthing of other equipments inside the cabinet should be connected to the grounding bar.

DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet

2.6 Connection and Fastening



  • Use anti-loose threaded connection as structure and bearer connection. Anchor bolt for fixing cabinet use hot dip galvanized bolts.
  • Door hinges use inner hinge mode.



DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet



2.7 Appearance and Surface Treatment



Cabinet surface coating is outdoor special powder coating, with white gray color (PANTONE 428C). The coating complies with GB/T 3181-2008 requirement.



3. Description



The cabinet is one compartment cabinet. The cabinet cooling use air conditioner and fans, to ensure the equipments operate normally at stable temperature range, so as to make the service life of the equipments much longer and their performance more stable.



4. Applications



The ET6060100-BA Outdoor Battery Cabinet is mainly used in wireless communication base station, such as 4G system, communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.



5. Packing and Shipping



DC48V Air Conditioner Outdoor Battery Cabinet , Outdoor Server Cabinet



Our Delivery Agent



The goods can be shipped by sea, by air, by courier, by land, by train, etc.

Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
