304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55

Certification
Good quality Two Compartments Outdoor Telecom Cabinet for sales
Good quality Two Compartments Outdoor Telecom Cabinet for sales
Timely response, professional skills, rigorous attitude, fast delivery, we are very satisfied, cooperation is very smooth.

—— Manish

From 1 sample to 45 sets, 76 sets, 200sets, we gradually established a strong trust. The cabinet quality is good and the design is reasonable.

—— Parmar

In the past three years, our cooperation is very cheerful, thanks for your company's technical support and patient service, the end user is very satisfied with the quality of outdoor telecom cabinet with cooling. Best wishes to our future cooperation.

—— Anthony

The air conditioner have been running for one and a half years. Cooling effective is good. Good after-sale service, and patiently instruct to use and solve technical problems. Environmental monitoring system is also running well, and remote monitoring the cabinet is very convenient.

—— Luis Alberto

I'm Online Chat Now

304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55

China 304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55 supplier
304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55 supplier 304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55 supplier

Large Image :  304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55

Product Details:

Place of Origin: Shenzhen, China (Mainland)
Brand Name: ESTEL
Certification: ISO9001, CE, 3C, FCC, TLC, IP55
Model Number: 161080720050002

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden case
Delivery Time: 15-20 working days
Payment Terms: T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability: 8,000 sets per month
Contact Now
Detailed Product Description
Material: 304 Stainless Steel Cabinet Lock: Anti-theft Three Point Lock(support Padlock)
Certificates: CE Color: Grey/optional
Cooling System: Air Conditioner Or Fans Ip Rating: IP55



304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55



1. Cabinet Parameters



Items Technical Parameter
Dimension

External Dimension:

W×D×H 750×700×2000mm

Layout 1 compartment
Equipment Installation Method 19” rack
Doors With one front door , and anti-theft three point lock for outdoor cabinet (support padlock).
Material 304 stainless steel, single wall with insulation
Ingress Protection IP55
Cooling System

1. Air conditioner:

1pcs,

2000W cooling capacity,

48VDC,

Installed on the front door

2. Fans:

2pcs,

48VDC

Lighting 48V LED lamps
Power Distribution Unit

1 Set



Cable Inlets The cable entry points is situated behind the cabinet and of 10 holes split 6 top and 4 bottom and easy upgradeable.
Cabinet and Componet Coating The cabinet is coated structural Grey (RAL7032)
Package Wooden Case with pallets



2. Cabinet Configuration



NO DESCRIPTION SPECS QUANTITY UNIT
1 Outdoor Telecom Cabinet

(1) Model:
(2) External Dimension: W×D×H 750×700×2000mm
(3) One compartment: including 19" rack
(4) With one front door, and anti-theft lock for outdoor cabinet (support padlock)
(5) Material: 304 Stainless Steel, single wall with insulation

(6) Wall mount

1 SET
2 Fan DC48V 2 PC
3 Air Conditioner Cooling Capacity: 2000W;
Power Supply: DC48V
On the front door
1 SET
4 LED Lamp Switch Used for controlling led lamp on/ off 1 PC
5 LED Lamp DC48V, used for illumination in the cabinet 1 PC
6 Power
Distribution
Unit





1 SET
7 Package Wooden case with pallet 1 SET



3. PDU System



304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55



4. Cooling System



4.1 Air conditioner with 2000W Cooling capacity, installed on the front door of the cabinet.



4.2 Fans:48VDC,2pcs, installed on the front door of the cabiet



5.Production Pictures



304 Stainless Steel 2000W Air Conditioner Cooling Outdoor Telecom Cabinet IP55



6.Our Delivery Agent



The goods can be shipped by sea, by air, by courier, by land, by train, etc.

Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
